MECHANICAL DATA
Cell Mono
Weight 21.5kg
Dimensions 1722±2mm*1134±2mm*30±1mm
Cable Cross Section Size 4mm²(IEC),12 AWG(UL)
No. of cells 108(6*18)
J-Box IP68, 3 diodes
Connector QC 4.10-351/ MC4-EVO2A
ELECTRICAL DATE(STC)
Rated Maximum Power(Pmax)[W] 420 425 430 435 440 445
Power Tolerance 0~+3%
Open Circuit Voltage(Voc) [V] 38.28 38.56 38.84 39.11 39.38 39.65
Maximum Power Voltage(Vmp) [V] 32.38 32.64 32.88 33.13 33.37 33.64
Short Circuit Current(lsc) [A] 13.65 13.7 13.75 13.8 13.85 13.9
Maximum Power Current(lmp) [A] 12.97 13.02 13.08 13.13 13.18 13.23
Module Efficiency[%] 21.50% 21.80% 22.00% 22.30% 22.50% 22.80%
